redquack

Transfer REDCap data to a database and use in R without exceeding available memory. Compatible with all databases but specifically optimized for DuckDB—a fast and portable SQL engine with first-class integration in R/Posit products.

Motivation

R objects live entirely in memory, causing three problems if not using a specialized framework:

1. You must load full datasets even if you only need a subset
2. Unused objects still consume memory
3. Large datasets can easily exceed available memory

redquack’s solution to this problem is to:

1. Request all of the REDCap record IDs to sequence in chunks
2. Process each chunk of the REDCap data in one R object at a time
3. Remove each object from memory after it has been transferred to the database

Features

• Auto-resume from incomplete transfers
• Auto-retry for API request failures
• Auto-convert data types for DuckDB
• Timestamped operation logs
• Status messages and progress bar
• Sound notifications (🔊 🦆)

Installation

From CRAN:

# install.packages("pak")
pak::pak("redquack")

Development version:

pak::pak("dylanpieper/redquack")

These packages are used in the examples and are not imported by redquack:

pak::pak(c("dplyr", "duckdb", "keyring"))

Setup API Token

Your REDCap API token allows R to interface with REDCap and should be stored securely. I recommend using the keyring package to store your API token. For example:

keyring::key_set("redcap_token")

Basic Usage

Data from REDCap is transferred to a database via a DBI connection in chunks of record IDs:

library(redquack)

duckdb <- DBI::dbConnect(duckdb::duckdb(), "redcap.duckdb")

result <- redcap_to_db(
  conn = duckdb,
  redcap_uri = "https://redcap.example.org/api/",
  token = keyring::key_get("redcap_token"),
  record_id_name = "record_id",
  chunk_size = 1000
  # Increase chunk size for memory-efficient systems (faster)
  # Decrease chunk size for memory-constrained systems (slower)
)

The function returns a list with class redcap_transfer_result:

• success: Logical if the transfer was completed with no failed processing
• error_chunks: Vector of chunk numbers that failed processing
• time_s: Numeric value for total seconds to transfer and optimize data

Database Structure

The database created by redcap_to_db() contains two tables:

1. data: Contains all exported REDCap records with optimized column types

   data <- DBI::dbGetQuery(duckdb, "SELECT * FROM data LIMIT 1000")

2. log: Contains timestamped logs of the transfer process for troubleshooting

   log <- DBI::dbGetQuery(duckdb, "SELECT * FROM log")

Data Types

Data is imported as VARCHAR/TEXT for consistent handling across chunks.

For DuckDB, data types are automatically optimized after transfer to improve query performance:

• INTEGER: Columns with only whole numbers
• DOUBLE: Columns with decimal numbers
• DATE: Columns with valid dates
• TIMESTAMP: Columns with valid timestamps
• VARCHAR/TEXT: All other columns remain as strings

In DuckDB, you can query the data to inspect the data types:

DBI::dbGetQuery(duckdb, "PRAGMA table_info(data)")

You can also automatically convert data types in R using readr:

readr::type_convert(data)

To optimize query performance with other databases, you must alter the data table manually.

Data Manipulation

Query and collect the data with dplyr:

library(dplyr)

demographics <- tbl(duckdb, "data") |>
  filter(is.na(redcap_repeat_instrument)) |>
  select(record_id, age, race, sex, gender) |>
  collect()

If you collect() your data into memory in the last step, it can make a slow process nearly instantaneous. The following example data is 2,825,092 rows x 397 columns:

system.time(
  records <- duckdb |>
    tbl("data") |>
    collect() |>
    group_by(redcap_repeat_instrument) |>
    summarize(count = n()) |>
    arrange(desc(count))
)
#>   user  system elapsed
#>  5.048   5.006   6.077

system.time(
  records <- duckdb |>
    tbl("data") |>
    group_by(redcap_repeat_instrument) |>
    summarize(count = n()) |>
    arrange(desc(count)) |>
    collect()
)
#>    user  system elapsed
#>   0.040   0.015   0.040

You can also write a Parquet file directly from DuckDB and use arrow. A Parquet file will be about 5 times smaller than a DuckDB file:

DBI::dbExecute(duckdb, "COPY (SELECT * FROM data) TO 'redcap.parquet' (FORMAT PARQUET)")

Remember to close the connection when finished:

DBI::dbDisconnect(duckdb)

Collaboration Opportunities

While this package is only optimized for DuckDB, I invite collaborators to help optimize it for other databases. The pathway I suggest right now is to target your edits in R/optimize_data_types.R. Feel free to submit a PR and share any other ideas you may have.

Other REDCap Interfaces

• redcapAPI (R package; provides a package comparison table)

• PyCap (python module)
